Comprehensive Interpretation of Stainless Steel Honeycomb Panel

Table of Contents

Stainless steel honeycomb panel is a kind of sandwich structure metal composite plate, it is in the upper and lower two layers of stainless steel panel, using light aluminum or stainless steel honeycomb core as the sandwich, through high-strength adhesive or composite process of integral compression molding. This structure draws lessons from the hexagonal geometric mechanics principle of the natural honeycomb, and has the advantages of light weight, high strength and high flatness. It is a popular material choice in modern architecture and indoor and outdoor decoration.

Honeycomb panels originally originated in the aerospace industry, where the dual requirements for lightweight and strength of the material led to the maturation and industrialization of the honeycomb sandwich design. Stainless steel honeycomb panels have been used in a wide range of commercial, residential and public buildings as the construction industry’s need for aesthetics, durability and ease of maintenance for high-end curtain walls, interiors, furniture panels and utilities has increased.

The background of its development shows that honeycomb panel is a product of modern architecture in pursuit of performance optimization and sustainable design. It retains the corrosion resistance, aesthetics, and workability of stainless steel, while significantly reducing weight and material consumption through its honeycomb structure, in line with modern green building’s goals for energy efficiency, carbon reduction, and lower construction costs.

For designers, owners, purchasers and general contractors, understanding the definition and background of honeycomb panels can help make sound material selection decisions in the early stages of a project, ensuring an ideal balance of function, appearance and cost.

Stainless Steel Honeycomb Panel
Core Structure & Production Process

Material Composition

Stainless steel honeycomb panel is mainly composed of three parts:

  • Upper and lower panels: 304 or 316 stainless steel is usually used, and brushed, mirror, titanium, black titanium, bronze and other surface treatments are optional according to the usage environment and budget.

  • Honeycomb core layer: optional aluminum honeycomb core or stainless steel honeycomb core, depending on the specific requirements for fire resistance, strength and weight.

  • Adhesive layer: High performance structural adhesive or composite film is used to ensure strong bonding through high temperature and high pressure lamination process.

JYF METAL uses high quality stainless steel raw materials and internationally certified adhesives in its production to ensure the honeycomb panels are structurally stable and weather resistant, and can be customized in terms of core type and panel specifications according to project requirements.

Honeycomb Construction Principles

The honeycomb core has a regular hexagonal cavity structure that mimics the geometric design of a natural honeycomb. Advantages offered by this structure include:

  • High Specific Strength: Extremely high strength per unit weight, supporting the flatness of the panel.

  • Lightweight: High number of cavities and low density in the core, significantly reducing the overall weight.

  • Flexural Stiffness: far greater flexural stiffness than solid panels at the same weight.

  • Energy absorption: has a certain cushioning shock absorption, sound insulation and heat insulation performance.

This mechanical principle is an important advantage of honeycomb panels over traditional solid stainless steel panels or composite panels, and is also an important feature valued by modern architects and engineers.

Production Process

The standard process of producing stainless steel honeycomb panels includes:

  • Panel cutting and pre-treatment (e.g. cleaning, brushing, PVD coating)
  • Expansion and shaping of honeycomb cores
  • Gluing and lamination
  • High temperature high pressure laminating
  • Finished product cooling, trimming
  • QC & Packaging

The whole process requires very high flatness and bonding strength, JYF METAL has a mature production line and strict quality management system, which can realize the mass production of high-end decorative grade panels.

Surface Treatment Process

In order to meet different architectural and interior design styles, stainless steel honeycomb panel can be subjected to a variety of surface treatments:

  • Brushed – delicate matte texture, fingerprint resistance

  • Mirror – highly reflective, strong sense of modernity

  • PVD coating – gold, black titanium, rose gold and other optional colors, wear-resistant and anti-oxidation

  • Etched, sandblasted, embossed, and other customized patterns

JYF METAL can provide according to the needs of customers’ designs One-stop customization solutions, supporting the unified style of large-area curtain walls, as well as flexible small batch production of specific textures and colors to help designers achieve unique visual effects.

Contact us

The Main Performance Advantages of
Stainless Steel Honeycomb Panels

In the material selection stage of architecture and interior design, what designers, owners, purchasers and general contractors are most concerned about is not only aesthetics, but also performance, ease of construction, maintenance costs and a series of comprehensive factors. Stainless steel honeycomb panels have outstanding advantages in these areas.

Light Weight and High Strength

  • Lightweight design: the cavity structure of honeycomb core layer significantly reduces the weight of the sheet, compared with solid stainless steel sheet of the same thickness, it can reduce the weight by more than 50%-70%.
  • High strength support: The hexagonal honeycomb structure evenly distributes pressure when under stress, avoiding localized deformation.
  • Design Flexibility: Light weight means lower installation load requirements, which is suitable for scenarios such as remodeling of old buildings, new construction of large-span curtain walls, suspended ceilings and cladding columns.

For designers and general contractors, the lightweight and high strength characteristics not only reduce the structural burden, but also reduce transportation and installation costs.

Outstanding Flatness

  • The honeycomb core structure provides uniform support inside and is not easy to warp or deform.
  • Even on large panel sizes (e.g., 1.5 m x 3 m, or even larger), excellent surface flatness is maintained.

The high flatness is perfect for modern minimalist design of curtain walls, interior walls, and large decorative backgrounds, and satisfies commercial spaces and public building projects with high demands on visual effects.

Good Sound Insulation and Heat Insulation Performance

  • The cavity structure of the honeycomb core layer can effectively absorb and block the propagation of sound waves.
  • The air inside the core layer is stagnant, which reduces the thermal conductivity and plays a certain heat insulation effect.

Although the sound and heat insulation effect of honeycomb panel is not comparable to professional sound insulation materials, it is a practical solution with both decorative and certain heat and sound insulation functions in the building interior hierarchy.

Excellent Fire Resistance

  • Stainless steel itself is non-combustible.
  • High-quality structural adhesives are available to meet building fire code requirements.

Choosing stainless steel honeycomb panels means that the project can easily pass the building fire audit, especially suitable for crowded shopping malls, airports, hospitals, subway stations and other public spaces.

Corrosion Resistance and Easy Cleaning

  • 304, 316 stainless steel surface has excellent corrosion resistance, adaptable to indoor and outdoor humid environment.

  • PVD coating or brushed treatment is more resistant to fingerprints, scratch resistance, easy to clean.

This is especially important for owners and purchasers – meaning low maintenance costs and long service life.

Rich Surface Effects and Customization Capability

  • A wide range of effects are available such as brushed, mirror, PVD metallic, etched patterns, embossed textures, and so on.

  • JYF METAL can produce exactly matching customized panels based on design drawings and effect samples.

For designers, it is the ideal vehicle for realizing unique ideas. For general contractors and purchasers, the ability to customize the factory means a higher degree of cooperation in construction and a more controllable schedule and budget.

Ease of Construction and Installation

  • Lightweight panels reduce the need for lifting equipment.

  • Lightweight panels reduce the need for lifting equipment. Precise prefabricated dimensions in the factory and less cutting on site shorten the construction period.

  • Compatible with standard keel system, support curtain wall, ceiling, package column, partition and other installation methods.

JYF METAL can provide complete installation suggestions and node drawings in project support to help general contractors deliver efficiently.

Contact us

Multi-scenario Application in Interior Decoration

Stainless steel honeycomb panel is not only ideal for facade curtain wall, but also very suitable for interior decoration field. Combining the modern aesthetics of metal with the high performance of honeycomb, it is a high-end choice for designers and building owners in a wide range of scenarios.

Wall and Backdrop Decoration

  • Main backdrop of a shopping mall atrium
  • Hotel lobby reception desk background
  • Office lobby elevator wall
  • High-end residential TV background wall

The large size, flatness and various surface treatments of honeycomb panels can easily meet a variety of design styles, such as modern minimalism and luxury.

  • Customized colors and textures to match the design effect.
  • Large surface without splicing appears.
  • Scratch-resistant, easy to clean, adapt to high-traffic environment.
  • Can be combined with the lighting system to create the atmosphere

Ceiling and Ceiling System

  • Airport terminal building large ceiling
  • Arc ceiling of shopping mall atrium
  • Office building elevator hall ceiling

Honeycomb panel is light weight and high rigidity, suitable for large span and complex curved shape. Its high-end metallic texture and rich surface treatment can create the iconic ceiling of high-quality commercial space.

  • Large panel width reduces seams.
  • Arc, folding line and other special molding processing.
  • High fire-retardant and fire-resistant grade.
  • Standardized installation system, convenient construction.

Columns and Facade Decoration

  • Giant columns in hotel lobby
  • Commercial complex elevator box facade
  • Columns of rail transportation platforms

Stainless steel honeycomb plate can realize round, square, oval and other kinds of package column modeling, the surface effect is high-end and uniform. Compared with solid metal plate, it is lighter in weight and higher in flatness, avoiding bulging and wave deformation.

  • Customized Curvature & Segmented Splicing
  • High-end PVD color selection
  • Precise factory prefabricated dimensions
  • Convenient for quick on-site installation

Interior Partitions and Screens

  • Office interior partitions
  • High-end restaurant room screen
  • Hotel room corridor partition

Honeycomb panels can be designed as lightweight, durable, double-sided exquisite partition screens, taking into account the sense of privacy and transparency, and can be used in combination with glass, wood veneer, light strips, etc., to meet the needs of diverse spatial segregation.

  • Decorative effect of double-sided metal panels
  • Built-in soundproof core material
  • Etched or embossed surface
  • Easy modular installation and maintenance

Furniture and Special Customization

  • Front Reception Desk
  • Bar tops
  • Display case facades
  • Art installations

Designers can take advantage of honeycomb panels’ lightweight, high-strength, customizable surface effects and incorporate them into custom furniture and art installations to achieve design freedom with metal materials.

  • Extra large face splice reduction
  • Complex shaped cuts
  • Variety of surface treatments
  • Support small batch customization
Contact us

Stainless Steel Honeycomb Panel
Customized Production Key Points

For designers, owners, purchasers and general contractors, understanding the customized production key points of honeycomb panels helps to communicate more accurately with the needs, reasonable planning time and budget.JYF METAL summarizes the following common key points in many years of engineering practice:

Structural Composition and Material Selection

  • Panel material:usually 304 or 316 stainless steel, the surface can be brushed, mirror, PVD, etching, embossing, etc.. According to the project positioning and budget to choose the appropriate material.
  • Backboard options:the same material can be used stainless steel, aluminum, galvanized steel, etc. to meet different strength and cost requirements.
  • Honeycomb core: Aluminum honeycomb core is the main material, lightweight and high-strength, standard hexagonal cells to ensure uniform support.
  • Panel thickness is usually in the range of 0.5-1.2mm
  • Back panel material can be adjusted according to budget
  • Honeycomb core thickness is commonly 5-25mm
  • Adhesive needs to meet the weather resistance, high temperature resistance, fire rating

Surface Process Selection

  • Brushed: modern, fingerprint resistant
  • Mirror: luxury and high brightness
  • PVD: gold, copper, black, bronze and other colors
  • Etching/Embossing: Customized patterns and brand logos are available

Designers can specify the surface process by selecting samples at the proposal stage, and JYF METAL provides a variety of standard and customized effects for selection.

Size and Shape Customization

  • Regular size such as 1200×2400mm, 1500×3000mm.
  • Extra-large board width is subject to confirmation of transportation and installation conditions.
  • Customized curved, folded and special geometric shapes are available

Factory prefabrication ensures accurate dimensions and neat seams for fast project installation.

Structural Adhesives and Fire Protection Requirements

  • Flame retardant adhesives that comply with building fire codes.
  • Provide high temperature and weather resistance certification report.
  • Meet the requirements of different national and regional standards

The structural adhesives used by JYF METAL have been rigorously tested to ensure that the panels are strong and durable in the long term.

Production and Delivery Cycle

  • Common production cycle is 20-25 days (depending on specification, quantity and surface process)
  • Special finishes or complex shapes may take longer
  • Large orders can be delivered in batches

We recommend that designers and purchasers allow sufficient time for customized production in their project scheduling, and JYF METAL can assist with detailed delivery plans.

Packaging and Transportation

  • Standard export wooden crate packaging
  • Multi-layer protection with pearl cotton and moisture-proof film
  • Sea, air and truck transportation can be arranged

For oversized or shaped parts, we can provide professional packing solution to reduce the transportation risk.

Contact us

JYF METAL's Advantages and Services

As a professional manufacturer of stainless steel honeycomb panels and metal decorative materials, JYF METAL is not only a supplier, but also a trustworthy partner for designers, homeowners, purchasers and general contractors.

Experienced Manufacturing Capability

  • More than 100 years of experience in manufacturing metal panels and customized products

  • Large-scale laser cutting, bending, surface treatment, honeycomb composite and other full-process equipment

  • Strict quality management system

This means we can guarantee consistency and high quality from raw materials to finished products.

Diversified Customization Support

  • Provide different surface treatment and PVD color
  • Support customized size and complex shape
  • Flexibility to meet project requirements with small batch prototyping

JYF METAL understands the uniqueness of design, and we are happy to assist customers in realizing their ideas.

Professional Engineering Services

  • Assist in deepening design drawings
  • Provide node samples and installation suggestions
  • Supporting technical docking for overseas projects

For general contractors and design companies, this greatly reduces communication costs and improves construction efficiency.

Efficient Delivery and Logistics Capability

  • Short cycle production for standard products
  • Stainless steel color plate about 10 days
  • Stainless steel profile about 15-20 days
  • Customized honeycomb panels about 20-25 days
  • Long-term cooperation of freight forwarding resources
  • Support sea transportation, air transportation, express multi-channel
  • Provide flexible delivery methods such as to port, door to door, etc.

JYF METAL understands the node pressure of international projects, and we will try our best to cooperate with customers’ delivery schedule.

Strict Quality Control

  • Comprehensive pre-factory inspection
  • Material certificate can be issued according to customer’s requirements
  • Strict standardization of surface color difference, stitching and flatness.

We believe that good quality is the cornerstone of long-term cooperation.

Considerate After-sales Service

  • Factory video or physical sample confirmation
  • Regular report on production progress
  • Technical guidance for installation and use
  • Quick response to after-sales problems

Whether it is designers, owners or general contractors, you can get reliable service guarantee.
